DL618(80w) corrosion proof led explosion proof light/explosion proof light fixtures

Model Number: DL618(80w)

LED Light Source: CREE

Input Voltage(V): AC110-240V

Lamp Power(W): 80

Lamp Luminous Flux(lm): 9100

CRI (Ra>): 80

Working Temperature(℃):-20°C ~ +50°C

Working Lifetime(Hour): 50000

IP Rating: IP66

Ex mark: Exd II 2G Ex db IIB + H2 T5 Gb / II 2D Ex tb IIIC T100°C Db

light source: Cree xm-L led

beam angle: 160

Housing: aluminium alloy

Product Details

DL618(80w) corrosion proof led explosion proof light/explosion proof light fixtures

Product Description

Specification of led explosion proof light:

1. Housing Construction

Die cast aluminum housing

Bracket: 316 stainless steel

Surface treatment: corrosion proof powder coated

2. Light Source

Cree XML LED

50,000 hours average rated life

160° beam angle

3. Lens

Heat-treated glass (GL)

Impact-resistant diffuse polycarbonate (OP)

4. Compliances

Watt: 80W

IP class: IP66

Ex-mark:Exd II 2G Ex db IIB + H2 T5 Gb / II 2D Ex tb IIIC T100°C Db

Initial Luminous Flux :9100 lumens


Packaging & Shipping

one pieces in one carton, unit weight: 10.5 kg


Product Show


Parameters

ModelDL618(80w)
ConstructionDie cast aluminum housing
MountingCeiling, Hook
Hardware316 stainless steel
Light source

Cree XM-L Light emitting diodes(LED)

Up to 9100 Lumens (fixture)

CRI > 80

5000-7000K

50000 hours rated life

Electrical

Input power : 80 W

Input Voltage: AC110-240 V ,50Hz

Reflector160 degree
LensClear Heat Treated Glass
FinishTextured polyester powder coat
Ambient operating Temperature-20°C ~ +50°C
IP ratedIP66
Unit Weight8 Kg
Size117*151*910mm
Ex MarkExd  II 2G Ex db IIB + H2 T5 Gb / II 2D Ex tb IIIC T100°C  Db
Warranty5 Years

Application

Application of led explosion proof light/flame proof lamp/explosion proof lighting fixtures

DL618 explosion proof lamp the fixture can be used to explosion proof area,ship,drilling platform,petrochemical plantetc.by different options. Drawing only 40w ,the fixture is energy efficient and replaces up to 250W metal halide lamp.
